Portable Blasting Monitor Tellus 7 Channel

  • Merk : Vibracord
  • Minimal Pembelian : 1 Unit
  • Maksimal Pembelian : 100 Unit
  • Pengiriman : 45 Hari Setelah Pembayaran
  • Lokasi : Jawa Barat - Depok
  • Harga : Rp. 123 / Unit
  • Dilihat : 1.010 Kali
  • Pembaruan : 10-11-2025 18:48
Dapatkan Spesifikasi Harga Portable Blasting Monitor Tellus 7 Channel Produk Terbaik dari CV. ALAT KESLING INDONESIA Distributor Alat Kesehatan Lingkungan (alat kesling) dan Alat Laboratorium

Produk Detail

Portable Blasting Monitor
Type         : Tellus 7 Channel
 Product  : Vibracord - Spanyol
Fungsi    : Alat ukur getaran ledakan / Blasting

Spesifikasi :
▪ Number of Channel  : 7 channel
▪ Sample rate  : 2048 SPS
▪ Frequency range  : 2 ~ 250 Hz (ISEE)
      1-315 Hz & 1-80 Hz (DIN 45669-1)
▪ Trigger mode  : Automatic  : Manual : External
▪ FFT Calculation : Equipment and computer
▪ Data transfer modes : USB Disk, Web Server
      FTP Server, SFTP Server
▪ Data Visualization  : Screen, Printer, WEB Server,
      FTP Server, E-mail
▪ Screen : 7" TFT Color 800x480 pixels
▪ Keyboard  : 8 keys
▪ Data storage memory : Up to 30.000 record
▪ Intenal power supply  : Li-Ion rechargeable battery
▪ Dimensions / weight : 370 x 230 x 100 / 3 kg
▪ Environmental : IP-65 (Equipment, IP-68 (Geophone)
▪ Complete Unit  :
1 Recording unit
2 Two  three-axis bloks geophones
3 Six spikes for fixation
4 One Microphone for air wave recording
5 Tripod for Microphone
6 External power supply
7 Analysis program
8 User Manual and Certificate Calibration
9 Carrying case
10 Printer Module : thermal printer with 58mm paper roll
